Spacial SF
The Spacial SF is Schneider Electric’s modular floor-standing steel enclosure system, engineered for housing complex low-voltage switchgear, control, and automation equSetent. Built to IEC 62208 standards, it offers a robust welded frame, high protection ratings up to IP55 and IK10, and exceptional versatility for large or custom configurations
Electrical Characteristics
| Applications | Automation, power distribution, control systems |
|---|---|
| Assembly | Welded structure or flat-pack option (SFN) |
| Door | Hinged, reversible, 120° opening |
| Finish | Epoxy-polyester powder, RAL 7035 |
| Frame Design | 30 mm pitch modular frame, 3 mm thick |
| IK Rating | IK10 |
| IP Rating | IP55 (according to IEC 60529) |
| Material | Galvanized steel frame, steel cladding panels |
| Standards | IEC 62208, IEC 61439-1/2 compatible, RoHS compliant |
| Type | Modular floor-standing enclosure system |
