Spacial CRN
The Spacial CRN is Schneider Electric’s range of wall-mounted steel enclosures, designed for the secure housing of low-voltage electrical and automation components in industrial and commercial environments. Built to IEC 62208 standards, it offers high mechanical strength, corrosion resistance, and protection ratings up to IP66 and IK10, ensuring reliable performance even in demanding conditions
Electrical Characteristics
| Applications | General-purpose control panels, industrial machines, low power distribution |
|---|---|
| Door | Reversible, with 120° opening |
| Finish | Epoxy-polyester powder, RAL 7035 light grey |
| IK Rating | IK10 (resistance to mechanical impact) |
| IP Rating | IP66 (according to IEC 60529) |
| Material | Steel |
| Mounting | Wall-mount or floor-mount with accessories |
| Protection | Double folded edges for door sealing and rigidity |
| Standards | IEC 62208, IEC 60529, RoHS compliant |
| Type | Wall-mounted compact enclosure (monobloc) |
