Prisma Set system M
The Prisma Set System M is Schneider Electric’s IEC 61439-1/2 type-tested low-voltage switchboard, engineered for reliability, safety, and scalability in demanding industrial, commercial, and infrastructure applications. Its modular design enables precise configuration, easy maintenance, and future expansion.
Electrical Characteristics
| Rated insulation voltage Uᵢ (V AC) | 1000 |
|---|---|
| Frequency (Hz) | 50/60 |
| Rated impulse withstand voltage (kV) | 12 |
| Rated operation voltage (V AC) | Up to 415 |
| Rated peak withstand current Iₚₖ (kA) | 220 |
| Main busbar rated current max. Iₑ (A) | 3200/4000/4250 |
| Rated short-time withstand current - Without Linergy (kA/1 s.) | 85 |
| Rated short-time withstand current - With Linergy (kA/1 s.) | 100 |
