Prisma Set system L
The Prisma Set System L is Schneider Electric’s IEC 61439-1/2 type-tested low-voltage switchboard, designed for reliable, safe, and efficient power distribution in small to medium-scale industrial, commercial, and infrastructure projects. Its compact, modular design offers flexible configurations, straightforward maintenance, and room for future expansion.
Electrical Characteristics
| Rated insulation voltage Uᵢ (V AC) | 1000 |
|---|---|
| Frequency (Hz) | 50/60 |
| Rated impulse withstand voltage (kV) | 8 |
| Rated operation voltage (V AC) | 415 |
| Main busbar rated current max. Iₑ (A) | 630 |
| Nominal rated current (A) | 630 |
| Rated short-time withstand current I꜀w (kA/1s) | 25 |
